| Heating (A7/W35) | 10 kW |
| Electrical P absorbed (A7/W35) | 2,02 kW |
| COP(A7/W35) | 4,95 |
| Heating (A7/W45) | 10 kW |
| Electrical P absorbed (A7/W45) | 2,67 kW |
| COP(A7/W45) | 3,75 |
| Heating (A7/W55) | 9,50 kW |
| Electrical P absorbed (A7/W55) | 3,06 kW |
| COP(A7/W55) | 3,10 |
| Cooling (A35/W18) | 9,90 kW |
| – P electric absorbed (A35/W18) | 2,18 kW |
| – EER (A35/W18) | 4,55 |
| Racer (A35/W7) | 8,20 kW |
| Electrical P absorbed (A35/W7) | 2,52 kW |
| EER (A35/W7) | 3,25 |
| Seasonal efficiency class LWT 35C: | A+++ |
| Seasonal efficiency class LWT 55C: | A++ |
| Compressor: | BLDC inverter |
| R32 refrigerant factory charge | 1,40 kg |
| Circulation pump | de tip inverter |
| Maximum pressure | 9 mCA |
| Expansion vessel (Volume) | 8 l |
| Hydraulic connections | 1 1/4 “ |
| Electrical resistance (back-up) | 3 kW |
| Beach water temperature – Cooling | 5~26 °C |
| Beach water temperature – Heating | 25~66 °C |
| Beach water temperature – Domestic Hot Water | 30~61 °C |
| Power supply | 230/50 V/Hz |
| Sound noise EN12102-1 | 60 dB/A |
| Beach outside temperature- Cooling | -5~43 °C |
| Beach outside temperature – Heating | -25~35 °C |
| Outdoor temperature beach – Domestic hot water | -24~43 °C |
| Tip | phase |
| Net weight | 121 kg |
| Dimensions (WxHxD) | 945x1385x526 mm |
