| Technical Specification | OAT | LWT | Indoor Unit | HN0913T NK0 |
| Outdoor Unit | HU071MR U44 |
| Nominal Capacity | Heating | 7°C | 35°C | kW | 7.00 |
| 7°C | 55°C | 5.50 |
| Cooling | 2°C | 35°C | 4.20 |
| 35°C | 18°C | 7.00 |
| 35°C | 7°C | 7.00 |
| Nominal Power Input | Heating | 7°C | 35°C | kW | 1.43 |
| 7°C | 55°C | 2.4 |
| Cooling | 2°C | 35°C | 1.20 |
| 35°C | 18°C | 1.56 |
| 35°C | 7°C | 2.59 |
| COP | Heating | 7°C | 35°C | W/W | 4.90 |
| 7°C | 55°C | 2.70 |
| 2°C | 35°C | 3.51 |
| EER | Cooling | 35°C | 18°C | W/W | 4.50 |
| 35°C | 7°C | 2.70 |
| Operation Range (Outdoor Temp.) | Heating | Min. ~ Max. | Min. ~ Max. | °C DB | -25 ~ 35 |
| Cooling | Min. ~ Max. | Min. ~ Max. | °C DB | 5 ~ 48 |
| Compressor | Type | - | Hermetic Sealed Scroll |
| Refrigerant | Type | - | R32 |
| GWP (Global Warming Potential) | - | 675 |
| Precharged Amount | q | 1,5 |
| t-CO2 eq | - | 1.013 |
| Piping Connections | Outer Diameter | Liquid | mm (inch) | Ø 9.52 (3/8) |
| Gas | mm (inch) | Ø 15.88 (5/8) |
| Length | | | | |
| Standard | m | 5 |
| Level Difference | Max. | m | 50 |
| Chargeless-Pipe Length | Max. | m | 30 |
| Additional Charging Volume | - | m | 10 |
| - | g/m | 40 |
| Rated Water Flow Rate (at LWT 35°C) | ℓ/min | 20.1 |
| Sound Power Level | Heating | Rated | dB(A) | 60 |
| Sound Pressure Level (at 1m) | Heating | Rated | dB(A) | 52 |
| Dimensions | Unit | W x H x D | mm | 950 × 834 × 330 |
| Weight | Unit | kg | 60.0 |
| Exterior | Color / RAL Code | - | Warm Gray / RAL 7044 |
| Electrical Specification | Outdoor Unit | HU071MR U44 |
| Power Supply | Voltage, Phase, Frequency | - | V, Ø, Hz | 220-240, 1, 50 |
| Rated Running Current | Cooling | A | 6.3 |
| Heating | A | 6.9 |
| Wiring Connections | Power Supply Cable (included earth, H07RN-F) | mm² x cores | 4.0 x 3C |
| Technical Specification | Indoor Unit | HN0913T NK0 |
| Operation Range | Heating | Min. ~ Max. | °C | 15 ~ 65 |
| (Leaving Water Temp.) | | | |
| Cooling | Min. ~ Max. | 5 ~ 27 (16 ~ 27) 1) |
| Domestic Hot Water | Min. ~ Max. | 15 ~ 80 2) |
| Domestic Hot Water Tank | Volume | ℓ | 200 |
| Material | - | Duplex Stainless Steel |
| Internal Thermal Protect Limit | °C | 85 |
| Main Water Pump | Model | - | Grundfos UPM3K 20-75 CHBL |
| Flow Sensor | Measuring Range | Min. ~ Max. | ℓ/min | 5 ~ 80 |
| Water Pressure Sensor | Measuring Range | Min. ~ Max. | bar (G) | 0 ~ 20 |
| Expansion Vessel (Heating Circuit) | Volume | ℓ | 8 |
| Safety Valve | Heating Circuit | Upper Limit | bar | 3 |
| DHW Circuit | Upper Limit | bar | 10 |
| Piping Connections | Refrigerant Circuit | Liquid (outside diameter) | mm (Inch) | Ø 9.52 (3/8) |
| | | |
| Gas (outside diameter) | mm (Inch) | Ø 15.88 (5/8) |
| Water Circuit | | | | |
| Inlet | Inch | Female G1" according to ISO228-1 (parallel pipe threads) |
| Outlet | Inch | Female G1" according to ISO228-1 (parallel pipe threads) |
| DHW Tank Water Circuit | | | | |
| Cold Inlet | Inch | Female G1" according to ISO228-1 (parallel pipe threads) |
| Hot Outlet | Inch | Female G1" according to ISO228-1 (parallel pipe threads) |
| Recirculation | Inch | Female G1" according to ISO228-1 (parallel pipe threads) |
| Sound Power Level | Heating | Rated | dB(A) | 42 |
| Dimensions | Unit | W × H × D | mm | 600 × 1,750 × 660 |
| Weight (without water) | Unit | kg | 118 |
| Exterior | Color / RAL Code | - | White / RAL 9016 |
| Electrical Specification | Indoor Unit | HN0913T NK0 |
| Wiring Connections | Power and Communication Cable (Included Earth, H07RN-F) | mm² x cores | 0.75 x 4C |
| Electric Heater | Type | - | Sheath |
| No. of Heating Coil | EA | 2 |
| Capacity Combination | kW | 3 |
| Heating Step | Step | 1 |
| Power Supply | V, Ø, Hz | 220-240, 1, 50 |
| Wiring Connections Power Supply Cable (Included Earth, H07RN-F) | mm² x cores | 1.5 x 3C |
| Rated Current | A | 13.0 |
